Suzuki instruction manual Page 81
81
MIDI
MIDI LOCAL CONTROL MODE - Local control refers to the fact
that normally, this Suzuki piano controls the internal tone
generator. This is the normal play mode. Local control can
be turned off, so that the piano does not play the internal
voices, however, the MIDI information is still transmitted via
the MIDI Out connector when notes are played on the piano.
At the same time, the internal tone generator can respond to
MIDI data received via the MIDI In connector.
MIDI INPUT CHANNEL SELECTION - You may select an indi-
vidual MIDI channel to receive MIDI data on. The power up
default setting is the OMNI mode which receives MIDI data
on all channels.
MIDI SPLIT INPUT LOWER CHANNEL MODE - This MIDI input
channel mode is used to select which MIDI input channel you
want to receive for the lower split piano MIDI data. The previ-
ous MIDI input mode will receive the upper split piano data.
MIDI OUTPUT CHANNEL SELECTION - You may select an
individual MIDI channel to transmit MIDI data on. The power
up default setting to transmit MIDI data is channel 1.
MIDI SLIT OUTPUT LOWER CHANNEL MODE - This MIDI output
channel mode is used to select which MIDI output channel
that you want to transmit on for the lower split piano data.
This MIDI data can be sent separately on a discrete MIDI
channel. The previous MIDI input mode will transmit the
upper split piano data. The default setting for this mode
transmits on channel two.
