Suzuki instruction manual Page 79
79
MIDI & VIDEO OUT JACKS
MIDI stands for Musical Instrument Digital Interface. This is a world wide standard
communication interface that enables electronic musical instruments and comput-
ers (of all brands) to communicate with each other so that instructions and other
data can pass between them. This exchange of information makes it possible to
create a system of MIDI instruments and devices that offers far greater versatility
and control than is available with isolated instruments. Whether you interface with
computers, sequencers, expanders or other pianos your Suzuki piano's technical
capabilities, and your musical horizons will be greatly enhanced.
For further information on MIDI and MIDI equipment please see the following
pages and on the web visit Google.com and search under - Basic MIDI.
MIDI CONNECTION - The MIDI terminals are located on the bottom
left portion of the piano
1.
MIDI In: This terminal receives MIDI data from an external
MIDI device.
2.
MIDI Out: This terminal transmits data from this instrument
to other MIDI devices. The transmitted data includes the note
and touch velocity produced while playing on the piano, as
well as voice changes, wheel operation, and recorded play-
back for the melody tracks. Demo songs and auto accompa-
niment are not transmitted.
3.
MIDI Thru - This terminal transfers data from the IN terminal
directly to other MIDI devices.
MIDI
THRU
OUT
IN
1
2
3
VIDEO OUTPUT - The Video Output Jack is located to the left of
the MIDI terminals on bottom left of the piano.
1.
Video Out: This terminal sends the NTSC (TV signal) to
your RCA Jack Video Input terminal on your TV.
The video output only sends the Karoake Text information to
your TV Screen
