Suzuki - instruction manual
72
DISK
DISK FEATURES -
The Disk features allows you to Load Songs, Save Songs, Delete Song
Files and Rename your song files.
Microphone Jack Input
Floppy Disk Drive "In Use"
Indicator LED Light
Piano Power On/Off
Indicator LED Light
INSERT THE DISK - Insert the 3.5" (HD 1.4mb only) disk into the disk drive with
the label side up and the metal shutter leading into the drive. Slide the
diskette into the drive until it clicks into place. The disk eject button on
the drive pops out when the disk is properly inserted.
NOTE: This Piano only functions with HD (Hi Density) 1.4mb Floppy
Disks. These HD 1.4mb disks are the only type currently sold in stores.
REMOVE THE DISK - To remove the diskette press the eject button on the disk
drive.
NOTE: To avoid loss or damage to the disk or the disk drive, do not
remove the disk drive from the unit, or turn the power off when the disk
drive indicator light is on.
DISK MAIN MENU SCREEN
1.
Press the DISK button to activate the Disk Menu screen.
The Disk's Buttons LED Indicator will turn on.
2.
Use the CURSOR buttons to highlight the menu you would like to access.
3.
Press the ENTER button to confirm your selection.
Follow the instructions on the screen as they are displayed
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
DISK MENU
Load Song
Save Song
Utility
Play Disk
ENTER
ESCAPE
CURSOR
DISK
