60
SETUP - PEDAL MENU
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
123456789012345678901234567890121234567890123456789012345678901212345
Pedal Assign
Start/Stop
Intro/Ending
Fill
Lower Hold
PEDAL ASSIGN - SETUP MENU
1.
Press the SETUP button.
2.
Use the SCREEN RIGHT button to access the second page of the setup
menu options.
3.
Use the CURSOR button to highlight the Pedal menu.
4.
Press the ENTER button to access the Pedal menu.
5.
Use the CURSOR button to select the following options, the pedal can only
be assigned to one.
PEDAL ASSIGN
The center pedal is the only assignable function pedal.
The sustain pedal (the pedal on the right), can only control the Sound
Channel Voice notes.
The soft pedal (on the left), is also not assignable like the Sustain Pedal.
Start/Stop -
When selected the center pedal function now responds like the START/
STOP button on the control panel.
Step on the center pedal to start or stop a selected Rhythm or Accompa-
niment feature.
The Center Pedal default mode is Start/Stop.
Fill -
When selected the center pedal function now responds like the Fill In
Buttons on the control panel.
When engaged the pedal triggers the Fill In of the currently selected Fill-
In to the main pattern or the Fill In to Variation.
Intro/Ending -
When engaged the center pedal function now responds like the Into/
Ending button on the control panel.
Therefore the pedal triggers an introduction or ending pattern.
Lower Hold -
When selected pressing the pedal will prevent notes below the split point
from being switched off until the pedal is released.
If lower hold from the key mode setup is engaged, the pedal can be used
to cancel notes that are played.
