Suzuki instruction manual Page 58
58
SETUP - EFFECTS MENU
Effect Setting
Effect
UPPER
Chorus 3
100
LAYER LOWER
100
100
EFFECTS (CHORUS) - SETUP MENU
1.
Press the SETUP button.
2.
Use the SCREEN RIGHT button to access the second page of the setup
menu options.
3.
Use the CURSOR button to highlight the Effects menu.
4.
Press the ENTER button to access the Effects menu.
5.
Use the CURSOR button to access the following options:
EFFECTS (CHORUS)
The Effect or Chorus enriches your performance by adding depth, texture
and spaciousness to your selected instrument voice.
Pressing the EFFECTS button on the control panel will toggle the Effects
Function on and off.
Select the type of Effect and adjust the level in the Effect menu.
UPPER - When reverb upper is turned on the Upper Sound Channel
Voice notes will sound with the selected Effect.
Use the VALUE +and - buttons to select a reverb level from 0-127.
Press the VALUE + and - buttons simultaneously to recall the default
level of 100.
LAYER - When reverb layer is turned on the layer Sound Channel Voice
notes will sound with the selected Effect.
Use the VALUE + and - buttons to select a reverb level from 0-127.
Press the VALUE + and - buttons simultaneously to recall the default
level of 100.
LOWER - When reverb lower is turned on the lower Sound Channel voice
notes will sound with the selected Effect.
Use the VALUE + and - buttons to select a reverb level from 0-127.
Press the VALUE + and - buttons simultaneously to recall the default
level of 100.
EFFECT TYPES
There are eight Effect types.
Use the VALUE + and - buttons to select an effect type from the list
below.
Chorus 1.
Chorus 2.
Chorus 3.
Chorus 4.
F B (feedback) Chorus applies a repeated sound effect.
Flanger gives an electronic swirl effect.
Short Delay offers a short delay effect.
F B (feedback) Delay applies a delayed repeated sound effect.
