ActiveX Tool Kit
S O F T W A R E
Programming Tools
Microsoft's Visual Basic and Galil's Tool Kit
make developing an operator interface for the
controller quick and easy.
Features
Provides 32-bit OCXs for handling controller communications
including support of interrupts
Objects install right into the Visual Basic tool box and are part
of the run-time environment
Pre-built objects for many functions including:
· Terminal for sending commands and editing programs
· Polling window for displaying responses from the controller
such as position and speed
· Storage scope for plotting real-time trajectories such as
position vs.time or X vs.Y
· Send file for sending DMC files
· Continuous array capture for data collection and teach
and playback
· Coordinate transformation
· Graphical display of 2D-motion path
· Diagnostics for capturing current configurations
· Vector Motion Tools to slow down around corners and
tool offset
Built-in dialog boxes for each object for easy selection of color,
size,location and text
Context sensitive help with hypertext links
Product Description
Galil's ActiveX Tool Kit is a powerful software package
that lets the designer quickly and easily create an opera-
tor interface for Galil's controllers.The Tool Kit provides
the OCX custom controls that are loaded directly into the
Visual Basic run-time environment.
Pre-built objects include a DMC terminal, polling
window, send files and storage scope functions. Dialog
boxes allow objects to be easily customized for color,
size, location and text.
The Tool Kit shortens the development time of an
operator interface from days or weeks to a matter of
hours. Plus, the tool kit is easy to use, making it ideal
for even the novice programmer.
System Requirements
8MB RAM minimum (16MB recommended)
Any current version of Windows (Windows 98SE or newer)
Visual Basic, Microsoft Visual C++, Borland C++, Delphi,
LabVIEW,Wonderware, HP VEE, or any products that sup-
port ActiveX or OLE controls
