Galil Motion Control 2004catalog Page 81
47.20 mm
57.00 mm
R 3.80 mm
38.00 mm 0^-0.021
7.00 mm
2.50 mm
20.50 mm
6.1 mm
70.00 mm
19.00 mm
C
C
C-C
4-5.00 mm
6.35 mm 0^-0.0
12
KtTorque Constant
EMF Constant
TcContinuous Torque
Continuous Current
TpPeak Torque
JmMoment of Inertia
Recommended Supply Voltage
mMaximum Speed
RArmature Resistance
LArmature Inductance
Maximum Temperature
TmElectro-mechanical Time Constant
Length with Encoder
Weight
Encoder Resolution
BLM-N23-50-1000
Motor Leads: Phase A--Blue, Phase B--White, Phase C--Red
MODEL NUMBER
PARAMETER
UNITS
BLM-N23-50-1000
Nm/A
oz-in/A
V/(rad/sec)
V/kRPM
Nm
oz-in
A
Nm
oz-in
kg ·m
2
oz-in-s
2
volts
rpm
ohm
mH
°C
°F
msec
mm
in
kg
lbs
lines/rev
0.08
11.4
8.4 × 10-2
8.8
0.32
46
4
2
286
1.7 × 10-5
2.42 × 10-3
48
5500
2
3
150
300
4
94
3.7
0.8
1.8
1000
BLM-N23-50-1000
Brushless Servo Motor
