DMC-1410, DMC-1411, DMC-1412
ISA, PC/104, RS232 Econo 1 axis
PART NUMBER
DESCRIPTION
QUANTITY 1 QUANTITY 100
DMC-1410
1-axis ISA
$ 595
$ 395
DMC-1411
1-axis PC/104
$ 595
$ 395
DMC-1412
1-axis stand-alone with RS232--card
$ 595
$ 395
DMC-1412-box
1-axis stand-alone with RS232 in enclosure with power supply
$ 795
$ 545
DMC-1414-box
DMC-1412 with internal brush servo amplifier and screw terminals
$ 995
$ 795
CABLE 37-pin D
37-pin cable for DMC-1410, DMC-1412
$ 25
CABLE 40-pin IDC
40-pin to 37-pin cable for DMC-1411
$ 25
CABLE 9-pin D
9-pin RS232 cable for DMC-1412
$ 10
ICM-1460
Interconnect Module for DMC-1400 series. Specify -HAEN for high amp enable
or -LAEN for low amp enable
$ 145
$ 95
ICM-1460-OPTO
ICM with optoisolated inputs and outputs
$ 195
$ 145
ICM-1460-20W
ICM-1460 with 20-watt amplifier
$ 220
$ 145
AMP-1460
ICM with on-board, PWM amplifier for 1 brush-type servo
$ 495
$ 345
Galil Utilities
Communication drivers, SmartTERM, DMCWIN software
$ 20 for CD; free download
DMCWIN32
Windows API Tool Kit (VB, C, C++, etc.)
Included with Utilities
WSDK
Set-up, tuning and analysis software
$ 195
ActiveX Tool kit
Custom ActiveX controls for Visual Basic or Visual C++
$ 595
Upgrade Options
Two sets of PID, anti-friction bias, absolute or SSI sensors, backlash and
leadscrew error compensation, profile smoothing,anti-resonance profiling,
high-resolution gearing, password protect, memory expansion,
Consult factory
closed-loop steppers, coordinate transformation
One-time set-up charge
-CER
Piezo-ceramic motor option
$ 400 set-up charge
Consult factory
Galil offers additional quantity discounts for purchases between 1 and 100. Consult Galil for a quotation.
