DMC-12x0, DMC-13x8, DMC-16x0, DMC-17xx Series
PC/104, VME, cPCI, ISA Optima 1 8 axes
Extended I/O DMC-13x8
(for DMC-1748 use CB-50-80)
80-pin, high density; Connector: 3M# n10280-52e2vc
Cable: Amp# 3-175677-0; Enclosure: Amp# 1-176793-0
1 Bit 7 - bank 6
41 Bit 7 - bank 2
2 Bit 0- bank 7
42 Bit 0- bank 3
3 Bit 6 - bank 6
43 Bit 6 - bank 2
4 Bit 1- bank 7
44 Bit 1- bank 3
5 Bit 5 - bank 6
45 Bit 5 - bank 2
6 Bit 2- bank 7
46 Bit 2- bank 3
7 Bit 4 - bank 6
47 Bit 4 - bank 2
8 Bit 3- bank 7
48 Bit 3- bank 3
9 Bit 3 - bank 6
49 Bit 3 - bank 2
10 Bit 4- bank 7
50 Bit 4- bank 3
11 Bit 2 - bank 6
51 Bit 2 - bank 2
12 Bit 5- bank 7
52 Bit 5- bank 3
13 Bit 1 - bank 6
53 Bit 1 - bank 2
14 Bit 6- bank 7
54 Bit 6- bank 3
15 Bit 0 - bank 6
55 Bit 0 - bank 2
16 Bit 7- bank 7
56 Bit 7- bank 3
17 Bit 7 - bank 5
57 Bit 7 - bank 1
18 Ground
58 Ground
19 Bit 6 - bank 5
59 Bit 6 - bank 1
20 Ground
60 Ground
21 Bit 5 - bank 5
61 Bit 5 - bank 1
22 Ground
62 Ground
23 Bit 4 - bank 5
63 Bit 4 - bank 1
24 Ground
64 Ground
25 Bit 3 - bank 5
65 Bit 3 - bank 1
26 Ground
66 Ground
27 Bit 2 - bank 5
67 Bit 2 - bank 1
28 Ground
68 Ground
29 Bit 1 - bank 5
69 Bit 1 - bank 1
30 Ground
70 Ground
31 Bit 0 - bank 5
71 Bit 0 - bank 1
32 Bit 7 - bank 4
72 Bit 7 - bank 0
33 Bit 6 - bank 4
73 Bit 6 - bank 0
34 Bit 5 - bank 4
74 Bit 5 - bank 0
35 Bit 4 - bank 4
75 Bit 4 - bank 0
36 Bit 3 - bank 4
76 Bit 3 - bank 0
37 Bit 2 - bank 4
77 Bit 2 - bank 0
38 Bit 1 - bank 4
78 Bitt 1 - bank 0
39 Bit 0 - bank 4
79 Bit 0 - bank 0
40 5 V
80 5 V
Connectors continued
Auxiliary Encoder
DMC-13x8*, DMC-1600*
36-pin, high density
Connector: Amp# 2-178 238-5
Cable: Amp#2-175677-5
Enclosure: Amp# 176793-5
1 5 V
19 5 V
2 Ground
20 Ground
3 AA+X
21 AA+E
4 AA-X
22 AA-E
5 AB+X
23 AB+E
6 AB-X
24 AB-E
7 AA+Y
25 AA+F
8 AA-Y
26 AA-F
9 AB+Y
27 AB+F
10 AB-Y
28 AB-F
11 AA+Z
29 AA+G
12 AA-Z
30 AA-G
13 AB+Z
31 AB+G
14 AB-Z
32 AB-G
15 AA+W
33 AA+H
16 AA-W
34 AA-H
17 AB+W
35 AB+H
18 AB-W
36 AB-H
*DMC-13x8 and DMC-1600 have X,Y, Z,W axes only
Auxiliary Encoder (Axis 14)
DMC-1700
(DMC-1200 uses 20-pin IDC)
26-pin IDC, (Axis 58) 26-pin IDC
1 5 V
2 Ground
3 AA+X,E
4 AA-X,E
5 AB+X,E
6 AB-X,E
7 AA+Y,F
8 AA-Y,F
9 AB+Y,F
10 AB-Y,F
11 +5 V
12 Ground
13 AA+Z,G
14 AA-Z,G
15 AB+Z,G
16 AB-Z,G
17 AA+W,H
18 AA-W,H
19 AB+W,H
20 AB-W,H
21 Sample clock
22 NC
23 NC
24 NC
25 NC
26 NC
