IOC-7007
Ethernet I/O Controller
PART NUMBER
DESCRIPTION
QUANTITY 1 QUANTITY 100
IOC-7007-BOX-AC
I/O Controller Base; BOX; 90 260 AC
$ 595
$ 495
IOC-7007-BOX-DC
I/O Controller Base; BOX; 2060 VDC
$ 595
$ 495
IOC-7007-DIN-DC
I/O Controller Base; DIN; 2060 VDC
$ 595
$ 495
IOC-7007-CARD-DC
I/O Controller Base; CARD; 2060 VDC (requires +5 V, ±12 V inputs)
$ 545
$ 445
IOC-7007-CARD-NS
I/O Controller Base; CARD; no supply
$ 495
$ 395
IOM-70016
I/O Module--16 TTL inputs
$ 30
$ 20
IOM-70108
I/O Module--8 optoisolated inputs
$ 30
$ 20
IOM-70208
I/O Module--8 optoisolated outputs (24 V @ 25 mA)
$ 30
$ 20
IOM-70308
I/O Module--8 low-side, high-power outputs (24 V @ 100 mA)
$ 30
$ 20
IOM-70508
I/O Module--8 high-side, high-power outputs (55 V @ 500 mA)
$ 45
$ 30
IOM-70404
I/O Module--4 dry contact relays (150 V @ 250 mA)
$ 55
$ 40
IOM-70808
I/O Module--8 analog inputs (12-bits)
$ 60
$ 45
IOM-70908
I/O Module--8 analog outputs (12-bits)
$ 60
$ 45
IOM-70904
I/O Module--4 analog outputs (12-bits)
$ 30
$ 20
Note: One IOC-7007 controller base accepts up to seven (7) IOM modules
Galil offers additional quantity discounts for purchases between 1 and 100. Consult Galil for a quotation.
Ordering Information
CONTROLLERS
--
ETHERNET
58
www.galilmc.com
/
Galil Motion Control, Inc.
Connectors
20-pin molex for each IOM module
IOM-70904
4 Analog output module
1
NC
2
NC
3
Analog Output 1
4
Ground
5
Analog Output 2
6
Ground
7
Analog Output 3
8
Ground
9
Analog Output 4
10
Ground
11
NC
12
NC
13
NC
14
NC
15
NC
16
NC
17
NC
18
NC
19
NC
20
NC
IOM-70904 4 Analog Outputs
On IOM-70904 side
Outside
GND
Analog Out
243 Ohms
Analog Output range: -10 V to +10 V
Output Resistance: 243 Ohms
IOM-70904 provides 4 outputs
TL084
