IOC-7007
Ethernet I/O Controller
IOM-70404
4 Dry Contact Relay Outputs
Outside On IOM-70404 side
Each Dry contact relay is rated for 150 V @ 250 mA
Vcc
DO
74LS595
RO_NC
RO_C
RO_NO
Connectors
20-pin molex for each IOM module
IOM-70508
8 Opto-isolated high power output module
1
NC
2
NC
3
Power Output 1 (+)
4
Power Output 2 (+)
5
Power Output 3 (+)
6
Power Output 4 (+)
7
Power Output 5 (+)
8
Power Output 6 (+)
9
Power Output 7 (+)
10
Power Output 8 (+)
11
NC
12
NC
13
NC
14
NC
15
VIN_ISO, Input for Power supply (+)
16
VIN_ISO, Input for Power supply (+)
17
VIN_ISO, Input for Power supply (+)
18
VIN_ISO, Input for Power supply (+)
19
VIN_ISO, Input for Power supply (+)
20
Ground_ISO, Input for Return supply (-)
IOM-70404
4 Dry contact relay output module
1
NC
2
NC
3
Relay Output Common 1
4
Relay Output Normally Open 1
5
Relay Output Normally Close 1
6
Relay Output Common 2
7
Relay Output Normally Open 2
8
Relay Output Normally Close 2
9
Relay Output Common 3
10
Relay Output Normally Open 3
11
Relay Output Normally Close 3
12
Relay Output Common 4
13
Relay Output Normally Open 4
14
Relay Output Normally Close 4
15
NC
16
NC
17
NC
18
NC
19
NC
20
NC
IOM-70808-12 8 Analog Inputs
IOM-70908 8 Analog Outputs
D
On IOM-70808 side
Outside
Ground
HI-508
Inputs 1..8
B
8
B
1
S
1
S
8
C
1
C
2
C
3
GND
V
in
Sign
V
ref
ENB
ENB
DC
Multiplexer
A/D Converter
8 Analog Inputs with Input range: -10 V to +10 V
Standard 12-bit resolution. 16-bit option available.
Part Number: IOM-70808 -12 (-16 for upgrade)
On IOM-70908 side
Outside
GND
Analog Out
243 Ohms
Analog Output range: -10 V to +10 V
Output Resistance: 243 Ohms
IOM-70908 provides 8 outputs
TL084
CONTROLLERS
--
ETHERNET
www.galilmc.com
/
Galil Motion Control, Inc.
57
GND_Iso
On IOM-70508 side
VIN_Iso
500 mA max on each output with 3 Amps max total at 5-24 VDC
4.7k
10k
10k
11V
Power Out
Outside
IOM-70508
8 Opto-isolated High Power Outputs
IOM-70808
8 Analog input module
1
NC
2
NC
3
Analog Input 1
4
Ground
5
Analog Input 2
6
Ground
7
Analog Input 3
8
Ground
9
Analog Input 4
10
Ground
11
Analog Input 5
12
Ground
13
Analog Input 6
14
Ground
15
Analog Input 7
16
Ground
17
Analog Input 8
18
Ground
19
NC
20
NC
IOM-70908
8 Analog output module
1
NC
2
NC
3
Analog Output 1
4
Ground
5
Analog Output 2
6
Ground
7
Analog Output 3
8
Ground
9
Analog Output 4
10
Ground
11
Analog Output 5
12
Ground
13
Analog Output 6
14
Ground
15
Analog Output 7
16
Ground
17
Analog Output 8
18
Ground
19
NC
20
NC
