DMC-14x5 Series and DMC-34x5 Series
Ethernet/RS232 Econo 1 2 axes
PART NUMBER
DESCRIPTION
QUANTITY 1 QUANTITY 100
DMC-1415-card (or -3415)
1-axis stand-alone with Ethernet & RS232
$ 595
$ 395
DMC-1415-box (or -3415)
DMC-1415 in enclosure with power supply
$ 795
$ 545
DMC-1425-card (or -3425)
2-axis controller for 2 servo motors
$ 695
$ 445
DMC-1425-box (or -3425)
DMC-1425 in enclosure with power supply
$ 895
$ 595
-STEPPER option
Controls 2 step motors instead of 2 servo motors
No extra charge
DMC-1416-brush
Controller with amplifier for brush motors
$ 995
$ 845
DMC-1416-brushless
Controller with amplifier for brushless motors
$1095
$ 895
CABLE 37-pin D
37-pin D-type cable
$ 25
CABLE 9-pin D
9-pin RS232 cable
$ 10
ICM-1460
Interconnect Module . Specify -HAEN for high amp enable
or -LAEN for low amp enable
$ 145
$ 95
ICM-1460-STEPPER
Interconnect for DMC-1425-STEPPER
$ 145
$ 95
ICM-1460-OPTO
ICM with optoisolated inputs and outputs
$ 195
$ 145
ICM-1460-20W
ICM-1460 with 20-watt amplifier
$ 220
$ 145
AMP-1460
ICM with on-board, PWM amplifier for 1 brush-type servo
$ 495
$ 345
DB-14064
Expansion board for 64 I/O (for card-level only)
$ 295
$ 195
Galil Utilities
Communication drivers, SmartTERM software
$ 20
for
CD; free download
DMCWIN32
Windows API Tool Kit (VB,C, C++, etc.)
Included with Utilities
WSDK
Set-up, tuning and analysis software
$ 195
ActiveX Tool Kit
Custom ActiveX controls for Visual Basic or Visual C++
$ 595
Upgrade Options
Two sets of PID, anti-friction bias, absolute or SSI sensors, backlash and
leadscrew error compensation, profile smoothing,anti-resonance profiling,
high-resolution gearing, password protect, memory expansion,
Consult factory
closed-loop steppers, coordinate transformation
One-time set-up charge
-CER
Piezo-ceramic motor option
$ 400 set-up charge
Consult factory
Galil offers additional quantity discounts for purchases between 1 and 100. Consult Galil for a quotation.
Ordering Information
CONTROLLERS
--
ETHERNET
