Galil Motion Control - 2004catalog
DMC-21x2 and DMC-21x3 Series
Ethernet/RS232 Econo 1­ 8 axes
PART NUMBER
DESCRIPTION
QUANTITY 1 QUANTITY 100
ICM-20100
DMC-21x3 Interconnect with D-type connectors (use 1 for every 4 axes)
$ 95
$ 75
ICM-20105
DMC-21x3 Interconnect for optically isolated I/O (use 1 for every 4 axes)
$ 195
$ 145
SDM-20240
DMC-21x3 Interconnect with four 1.4A stepper drivers
$ 195
$ 175
AMP-20340
DMC-21x3 Interconnect with four 20W servo drives
$ 195
$ 175
AMP-20420
DMC-21x3 Interconnect with two 200W servo drives
$ 395
$ 245
AMP-20440
DMC-21x3 Interconnect with four 200W servo drives
$ 595
$ 295
AMP-20520
DMC-21x3 Interconnect with two 500W servo drives (includes 8 analog inputs)
$ 595
$ 395
AMP-20540
DMC-21x3 Interconnect with four 500W servo drives (includes 8 analog inputs)
$ 795
$ 495
SR-19900
Shunt regulator for AMP-205x0
$ 75
$ 40
CABLE-15-1M
15-pin high-density D sub to discrete wires--1-meter (for AMP-205x0)
$ 25
$ 17
CABLE-15-2M
15-pin high-density D sub to discrete wires--2-meter (for AMP-205x0)
$ 30
$ 20
CABLE-44-1M
44-pin high-density D sub to discrete wires--1-meter (for AMP-205x0)
$ 35
$ 24
CABLE-44-2M
44-pin high-density D sub to discrete wires--2-meter (for AMP-205x0)
$ 40
$ 27
CABLE-Ethernet
Ethernet cables
Consult factory
CABLE-9-pin D
RS232 cable
$ 10
CABLE-100-1M
100-pin high-density cable in 1-meter length for DMC-21x2
$ 125
$ 95
CABLE-100-2M
100-pin high-density cable in 2-meter length for DMC-21x2
$ 135
$ 100
CABLE-100-4M
100-pin high-density cable in 4-meter length for DMC-21x2
$ 150
$ 105
ICM-2900
Interconnect module (use 1 for every 4 axes) for DMC-21x2. Specify -HAEN for
high amp enable or -LAEN for low amp enable. Specify -FL for flange
$ 295
$ 195
ICM-2900-OPTO
ICM with optoisolated outputs for DMC-21x2
$ 345
$ 245
AMP-19520
DMC-21x2 Interconnect with two 500 W servo drives; connects to CABLE-100
$ 595
$ 395
AMP-19540
DMC-21x2 Interconnect with four 500 W servo drives; connects to CABLE-100
$ 795
$ 495
IOC-7007
Intelligent I/O controller box for Ethernet I/O expansion
$ 595
$ 495
Galil Utilities
Communication drivers, SmartTERM, DMCDOS
$ 20 for CD; free download
DMCWIN32
Windows API Tool Kit (VB, C, C++, etc.)
Included with Utilities
WSDK
Set-up, tuning and analysis software
$ 195
ActiveX Tool Kit
Custom ActiveX controls for Visual Basic or Visual C++
$ 595
Galil offers additional quantity discounts for purchases between 1 and 100. Consult Galil for a quotation.
Ordering Information -- continued
Common DMC-21x3 Configurations:
DMC-2143
4-axis card for +5 V, +/-12 V power input; 96-pin vertical
DMC-2143-H
Above with 96-pin horizontal connector
DMC-2143-DC24-DIN
4-axis with DIN-rail mount and DC-to-DC converter for 24 V input
CONTROLLERS
--
ETHERNET
46
www.galilmc.com
/
Galil Motion Control, Inc.
