DMC-21x2 and DMC-21x3 Series
Ethernet/RS232 Econo 1 8 axes
Ordering Information
The DMC-21x2 and DMC-21x3 series are available with various options as described below:
DMC-21x2
- H
- DC24 - DIN - VP
Axis number
100-pin & Enet/RS232 Connectors DC-to-DC Converter
DIN-rail Mount
6-pin Molex Power Connector
x=1 thru 8
H= horizontal (default)
- none (default) - none (default) VP = vertical (default)
V= vertical
- DC24 (1836 Volts) - DIN (requires V option) HP = horizontal
- DC48 (3672 Volts)
The default configuration of the DMC-21x2 is with horizontal connector mount for the communication and 100-pin connectors
and vertical mount for the power connector, no DC-to-DC and no DIN rail mount.
DMC-21x3
- V - DC24
- DIN - UP - VP
Axis number Enet/RS232 Connectors DC-to-DC Converter DIN-rail Mount 96-pin config.
6-pin Molex Power Connector
x=1 thru 8 V= vertical (default)
- none (default) - none (default) - UP (default) VP = vertical (default)
H=horizontal
- DC24 (1836 Volts) - DIN (requires V
- DOWN
HP = horizontal
- DC48 (3672 Volts) and UP option)
- RA (right angle)
The default configuration of the DMC-21x3 is with vertical communication and power connector mount, no DC-to-DC, no DIN rail mount and UP 96-pin connector configuration.
PART NUMBER
DESCRIPTION
QUANTITY 1 QUANTITY 100
DMC-2112
1-axis Ethernet 10BASE-T, RS232 card, 100-pin SCSI
$ 795
$ 595
DMC-2122
2-axis Ethernet 10BASE-T, RS232 card, 100-pin SCSI
$ 895
$ 665
DMC-2132
3-axis Ethernet 10BASE-T, RS232 card, 100-pin SCSI
$1045
$ 725
DMC-2142
4-axis Ethernet 10BASE-T, RS232 card, 100-pin SCSI
$1195
$ 795
DMC-2152
5-axis Ethernet 10BASE-T, RS232 card, 100-pin SCSI
$1295
$ 845
DMC-2162
6-axis Ethernet 10BASE-T, RS232 card, 100-pin SCSI
$1395
$ 895
DMC-2172
7-axis Ethernet 10BASE-T, RS232 card, 100-pin SCSI
$1495
$ 945
DMC-2182
8-axis Ethernet 10BASE-T, RS232 card, 100-pin SCSI
$1595
$ 995
DMC-2113
1-axis Ethernet 10BASE-T, RS232 card, 96-pin DIN
$ 795
$ 595
DMC-2123
2-axis Ethernet 10BASE-T, RS232 card, 96-pin DIN
$ 895
$ 665
DMC-2133
3-axis Ethernet 10BASE-T, RS232 card, 96-pin DIN
$1045
$ 725
DMC-2143
4-axis Ethernet 10BASE-T, RS232 card, 96-pin DIN
$1195
$ 795
DMC-2153
5-axis Ethernet 10BASE-T, RS232 card, 96-pin DIN
$1295
$ 845
DMC-2163
6-axis Ethernet 10BASE-T, RS232 card, 96-pin DIN
$1395
$ 895
DMC-2173
7-axis Ethernet 10BASE-T, RS232 card, 96-pin DIN
$1495
$ 945
DMC-2183
8-axis Ethernet 10BASE-T, RS232 card, 96-pin DIN
$1595
$ 995
DMC-31x3
DMC-21x3 with distributed control functionality
Same price as DMC-21x3
-DIN
DIN-rail mount option for DMC-21x2/x3
$ 100
$ 50
-DC24
DC-to-DC converter for 18 V to 36 V
$ 100
$ 70
-DC48
DC-to-DC converter for 36 V to 72 V
$ 100
$ 70
DB-28040
I/O expansion board for 8 analog inputs and 40 digital I/O (outputs source 3.3 V)
$ 295
$ 195
DB-28040-5V
I/O expansion board for 40 digital I/O (maximum 24 digital outputs) and
8 analog inputs. Outputs are open collector and sink 5 V
$ 295
$ 195
Accessories for DMC-21x2/x3 are continued on the next page.
