MBA-6-60
90
Power Amplifers
·
Galil Motion Control, Inc.
·
800-377-6329
BRUSHLESS
Adjustments
Connectors
MBA-6-60 Schematic
MBA-6-60 has four potentiometers that can be adjusted.
The output voltage of each potentiometer is measured at
the respective probe hole in front of the potentiometer.
Potentiometer 1--Loop Gain
CW rotation increases the amplifier gain.
At extreme counterclockwise setting, the gain is 1
Potentiometer 2--Current Limit
CW rotation increases the current limit
Range: 0-10 V, where 10 V give 6 amps continuous
The peak current limit equals twice the continuous limit and lasts
for 2 sec.
Potentiometer 3--Reference Input Gain
CW rotation increases the input gain.
At extreme clockwise setting the gain is 1.
Potentiometer 4--Offset Voltage
The sensitivity of the offset voltage is increased 50 times by closing SW4.
Range: ±15 V
POWER CONNECTOR; 5-PIN SCREW-TYPE:
1 Motor phase A
2 Motor phase B
3 Motor phase C
4 Power ground
5 Supply voltage +
SIGNAL CONNECTOR; 16-PIN MOLEX:
1 10 V, 5 mA out (available for customer use, short-circuit protected)
2 Ground
3 -10 V, 5 mA out (available for customer use, short-circuit protected)
4 +Reference input (differential analog input from Galil controller;
±10 V max; 50KW input resistance)
5 -Reference input
6 -Tachometer feedback (±60 V analog signal max; 60KW input resistance)
7 +Tachometer ground
8 Current monitor .5 V = 1 A
9 Inhibit* (low-level TTL inhibits amplifier; internal pull-up)
10 5 V
11 GND
12 HALL-1
13 HALL-2 HALL sensor inputs, TTL level, internal 2KW pull-up
14 HALL-3
15 Current command .5 V = 1 A
16 Fault out (TTL level; high designates fault)
* Active low
}
