Cannondale Bicycle Corp. 116378 OMS Scalpel EN web Page 30
28
SPECIFICATIONS
ITEM
SPECIFICATION
Model
Scalpel
Scalpel SI
Frame material
6061-T6, Tig welded, Aluminum Alloy
Sizes
S,M,L,XL
Recommended Sag
25%
Maximum tire width
2.1 in
Head tube
Headshok, OnePointFive
Head tube height
114mm (4.5 in)
Maximum fork length
500mm (19.7)
Seat post diameter
27.2 mm (1.07 in)
Rear shock mounting bolt diameter
6mm (.23 in)
Rear shock bushing width upper
16mm (.63 in)
Rear shock bushing width lower
22mm (.87 in)
Rear shock eyelet-to-eyelet length
5.5"
Rear wheel travel
67mm, 2.7 in
Rear shock stroke length
1"
Rear shock leverage ratio
2.7:1
Front derailleur
31.8mm Bottom Pull, Traditional Swing
Bottom bracket shell (width, thread type)
68 mm, English
SI Hollowgram
Chain Line
47.5 mm
Dropout Spacing
135 mm
Rear hub spacing
135 mm
Rear axle
Quick Release
Rear brake mount
International Standard,
6" only
