GEMINI
Gemini 2000, Gemini 900
SIZE
SMALL
MEDIUM
LARGE
X-LARGE
STL
Seat Tube Length (cm/in)
40.5/15.9
43.0/16.9
48.0/18.9
53.0/20.9
TTH
Top Tube Horizontal (cm/in)
57.5/22.6
60.0/23.6
62.5/24.6
65.0/25.6
TTA
Top Tube Actual (cm/in)
53.1/20.9
55.7/21.9
59.0/23.2
62.8/24.7
HTA
Head Tube Angle (degree)
67.0
STA
Seat Tube Angle (degree)
71.0
70.5
70.5
70.0
SO
Standover (cm/in)
72.4/28.5
73.0/28.7
73.3/28.9
75.4/29.7
WB
Wheel Base (cm/in)
09.2/43.0
111.5/43.9
114.5/45.1
116.8/46.0
FC
Front Center Distance (cm/in)
66.4/26.1
68.7/27.0
71.5/28.1
73.8/29.1
BBH
Bottom Bracket Height (cm/in)
36.3/14.3
BBD
Bottom Bracket Drop (cm/in)
-2.0/-0.8
CSL
Chainstay Length (cm/in)
43.2/17.0
Fork Crown Height (cm/in)
53.0/20.9
RK
Fork Rake (cm/in)
4.6/1.8
TR
Fork Trail (cm/in)
9.6/3.8
Rear Travel (cm/in)
15.0-
17.0/5.9-6.7
Shock Eye-to-Eye (cm/in)
20.0/7.875
Shock Stroke (cm/in)
5.7/2.25
Recommended Sag
30%
These dimensions are given with the bike suspension fully extended.
