P.43
CAPÍTULO QUATRO
Inspeção, Ajuste e Lubrificação
6. Instale o suporte do reboque (Figura 4.38) da abraçadeira de
fixação do braço da roda esquerda.
Certifique-se de que a extremidade do suporte do reboque passe
completamente pela abraçadeira, conforme indicado pela Advertência
localizada no suporte. Verifique ainda que os furos da abraçadeira e do
suporte estão alinhados.
7. Instale o pino de travamento esquerdo e feche o clipe de trava-
mento.
8. Fixe o suporte de reboque da bicicleta à bicicleta, como demons-
trado nas páginas 19-22.
