2002 Trek Technical Manual
GEARING
22 32 44
11 52 76 105
12 48 70 96
14 41 60 82
16 36 52 72
18 32 47 64
21 27 40 55
24 24 35 48
28 21 30 41
32 18 26 36
FIT
Frame Size 14 16 18
Rider height Inches 63 65 68
Cm 159 164 173
Handlebar Width, mm 600 600 600
Stem Length, mm 60 75 90
Angle 5 5 5
Crank Length, mm 170 170 175
Seatpost Length, mm 300 300 350
Steerer Length, mm 178.2 178.2 193.2
BIKE WEIGHT
26.1 lb.
11.85 kg.
Key features:
Rider: Every day woman enthusiast or aggressive
newbie
Frameset
Alpha SLR butted aluminum - light, strong, and
stiff
WSD geometry- Fit and performance for her
Wheelset
Bontrager Superstock- light and strong
Bontrager Jones AC- all-round tread
Components
All-round level (LX and Deore)-all round perfor-
mance with 9 speed and powerful brakes
WSD forks, handlebars, grips, saddle, cranks to fit
and perform for a woman
6700 WSD
FRAMESET
MAIN TUBES . . . . . . . Alpha SLR aluminum
STAYS . . . . . . . . . . . . . Alpha SLR aluminum
Frame weight
4.2 lb (1.91 kg)
FORK . . . . . . . . . . . . . . RockShox Duke C, light springs
Travel, mm
80
Axle-crown length, mm
451
HEADSET . . . . . . . . . . STR Aheadset
Size
25.4/34.0/30.0
Stack height, mm
23.2
CONTROLS
HANDLEBAR . . . . . . . Bontrager Crowbar Sport
Clamp diameter, mm
25.4
STEM . . . . . . . . . . . . . . Bontrager Select
Steerer clamp height, mm
41.0
SHIFT LEVERS . . . . . . Shimano Deore RapidFire+
BRAKE LEVERS . . . . . Alloy, direct pull, woman's reach
GRIPS . . . . . . . . . . . . . Bontrager Race, dual density
DRIVETRAIN
FT DERAILLEUR . . . . Shimano Deore
Cable routing
Top pull
Attachment
Plate style w/34.9mm clamp
RR DERAILLEUR . . . . Shimano Deore LX SGS
CRANKSET . . . . . . . . . Bontrager Select 44/32/22
Bolt hole circle, mm
64/104
BB . . . . . . . . . . . . . . . . Shimano BB-LP27
Shell x axle, mm
73 x 113, Square
CHAIN . . . . . . . . . . . . . Shimano HG-53
Chain type
3/32"
Chain length (links)
108
CASSETTE . . . . . . . . . SRAM 7.0 11-32, 9spd
WHEELSET
FRONT WHEEL . . . . . . Bontrager Superstock, 24°
E.R.D., mm
542
Rim strip
Velox 19mm
FRONT TIRE . . . . . . . . Bontrager Jones AC
Tire size
49/54
REAR WHEEL . . . . . . . Bontrager Superstock, 28°
E.R.D., mm
542
Rim strip
Velox 22mm
REAR TIRE . . . . . . . . . Bontrager Jones AC
Tire size
49/54
SPOKES . . . . . . . . . . . . DT 14G stainless
Front, mm
254, Radial
Rear, mm
267/269, 3x
INNER TUBES . . . . . . Presta valve, ultra light
OTHER
SEATPOST . . . . . . . . . Bontrager Sport
Outer diameter, mm
31.6
SADDLE . . . . . . . . . . . . Bontrager FS 2000 WSD
BRAKES . . . . . . . . . . . Shimano M420, V type
PEDALS . . . . . . . . . . . . Shimano SPD M515, clipless
Axle diameter
9/16"
SEAT BINDER . . . . . . . Alloy w/quick release
Inner diameter, mm
36.4
ADDITIONALS . . . . . . 2 water bottle mounts, rack mounts (1 bottle/
no rack on 14)
COLORS
Candy Blue/Starry Night · White/Red decals · White fork
