Table 5 (cont'd)
Propane/Iso-butane/N-Butane
Liquid Compositions in Mole Percent
Analysis by Gas Chromatography
Run Number
20841
20842
20843
20844
20845
20846
20847
20848
Mol % C3
Reflux
1.26
1.65
1.59
1.88
1.84
0.96
1.22
1.00
Tray 8 inlet
1.04
1.71
1.84
1.78
1.62
0.46
0.75
0.68
Tray 8 out
0.54
1.01
0.77
0.70
0.81
0.45
0.59
0.74
Tray 7 out
0.21
0.50
0.44
0.52
0.49
0.49
0.48
0.41
Tray 6 out
0.20
0.24
0.36
0.12
0.23
0.39
0.69
0.72
Tray 5 out
0.26
0.18
0.12
0.27
0.13
0.39
0.39
0.63
Tray 4 out
0.02
0.05
0.07
0.10
0.03
0.33
0.25
0.37
Tray 3 out
0.00
0.29
0.03
0.00
0.09
0.34
0.32
0.35
Tray 2 out
0.00
0.00
0.00
0.00
0.00
0.24
0.13
0.40
Tray 1 out
0.09
0.15
0.11
0.30
0.12
0.24
0.12
0.25
Bottoms
0.00
0.00
0.00
0.00
0.00
0.12
0.38
0.19
Feed
0.00
0.15
0.05
0.00
0.00
0.11
0.04
0.16
Mol % iC4
Reflux
58.33
58.75
58.69
63.99
63.92
35.09
37.98
34.67
Tray 8 inlet
58.01
58.39
58.20
63.89
63.92
30.40
33.23
30.14
Tray 8 out
52.90
53.31
53.47
58.82
58.87
30.62
33.44
30.27
Tray 7 out
47.61
48.18
48.18
52.46
53.64
37.37
33.31
30.21
Tray 6 out
42.86
44.04
43.90
48.28
48.32
30.60
33.21
30.27
Tray 5 out
37.77
39.75
39.55
42.31
42.32
30.66
32.84
30.35
Tray 4 out
33.40
35.22
35.31
36.97
36.70
30.48
32.38
30.24
Tray 3 out
28.64
30.96
30.90
31.91
31.88
30.29
31.50
30.11
Tray 2 out
24.72
26.92
26.99
27.02
27.00
29.82
30.05
29.94
Tray 1 out
21.27
23.53
23.34
22.29
22.56
28.96
28.38
29.43
Bottoms
18.15
19.65
19.68
19.24
19.08
26.98
25.73
27.70
Feed
17.99
19.76
20.17
19.21
19.12
26.98
25.68
27.67
Mol % nC4
Reflux
40.42
39.60
39.73
34.13
34.24
63.96
60.80
64.33
Tray 8 inlet
40.95
39.90
39.96
34.33
34.45
69.15
66.03
69.19
Tray 8 out
46.57
45.68
45.76
40.48
40.33
68.93
65.97
69.00
Tray 7 out
52.18
51.32
51.38
47.02
45.88
62.14
66.21
69.38
Tray 6 out
56.94
55.72
55.75
51.59
51.45
69.02
66.10
69.01
Tray 5 out
61.97
60.07
60.34
57.42
57.55
68.95
66.78
69.02
Tray 4 out
66.58
64.73
64.63
62.93
63.28
69.19
67.38
69.39
Tray 3 out
71.36
68.75
69.07
68.09
68.03
69.37
68.19
69.54
Tray 2 out
75.28
73.08
73.01
72.99
73.00
69.93
69.82
69.66
Tray 1 out
78.64
76.32
76.55
77.41
77.33
70.80
71.49
70.32
Bottoms
81.85
80.35
80.32
80.76
80.92
72.91
73.90
72.12
Feed
82.01
80.09
79.78
80.79
80.88
72.91
74.29
72.17
