10
PLACE THE PIANO ON THE STAND, ATTACH THE CABLES AND
PLUG IN
4.
Attach the piano to the stand using the four Hand Bolts.
5.
Plug in the Pedal Board Cable located in the Pedal Board to the bottom,
back portion of the bottom right hand side of the piano.
6.
If everything is in its proper place then you should do all your final
tightening now.
3
PLACE THE
PIANO
ON THE
STAND,
Attach the piano to the stand with
the Hand Bolts.
Plug in the Pedal Board Cable
located in the Pedal Board to
the bottom of the piano.
ASSEMBLY HP-97
PLUG IN, TURN
ON, ADJUST THE
VOLUME AND
BEGIN TO PLAY
1.
PLUG IN THE AC CORD - Plug the AC Cord into the AC Receptacle Jack on the
back left portion of the panel. Then plug the AC cord into the 110V wall outlet.
2.
TURN THE POWER SWITCH ON - Turn on the power switch located on the left
side of the keyboard (O is off, and is on). The display will welcome you and
set the voice to Grand Piano automatically. The display will show "01: Grand
Piano1".
NOTE: When you turn the power off, do not turn the power back on immedi-
ately. Wait at least five seconds to turn the power back on so that the circuit
can properly reset.
3.
SET THE VOLUME TO THE DESIRED SETTING - Adjust the volume control to a
comfortable level by sliding the Master Volume control left, for softer sound or
right, for louder sound.
4.
BEGIN TO PLAY!
POWER
4
MASTER VOLUME
MIN MAX
NOTE THE NOTCH IN THE LEG PLATE
FITS AROUND THE HAND BOLT
