Position the Monitor
Bring the monitor assembly into the model and position it.
1. Merge the contents of the latest B_MONnn file into the B_MAINnn
file you've been working with.
2. Move and rotate the monitor assembly as shown (see Figure 4.41).
C
H A P T E R
4 : M
O D E L I N G
: B
E Y O N D
T H E
B
A S I C S
209
F
IGURE
4.40
Merge the thruster
assembly file into the
main model and position
it as shown.
F
IGURE
4.41
Merge the monitor
assembly file into the
main model and position
it as shown.
